Twin Post Fully Hydraulic In-Ground Service Jack – 16 Ton (with Complete Installation)

Description

The MECTRON Twin Post Fully Hydraulic In-Ground Service Jack – 16 Ton is designed for heavy commercial vehicle workshops, fleet maintenance depots, and washing bays handling buses, trucks, and heavy-duty vehicles. The twin-post configuration (8T + 8T) ensures balanced lifting, enhanced safety, and smooth synchronized operation for high-load applications.

Standard Equipment Included

• Independent Intermediate Oil Reservoir (IOR) – 2 Nos.

• Heavy-duty H-Type Beams

• Independent air control valve for each service jack – 2 Nos.

• 3-way air control valve for simultaneous operation of both jacks

• Twin hydraulic lifting cylinder assemblies

• Complete in-ground service jack mechanism

Key Features

• High-grade steel plungers manufactured to close tolerances with hard chrome plating for excellent wear resistance and long service life

• Outer cylinders coated with Fiber Reinforced Plastic (FRP) to provide superior corrosion protection in wet and harsh environments

• Specially designed wiper rings prevent ingress of water, dust, and contaminants into the hoist cylinders during lifting and lowering operations

• Heavy-duty gland rings engineered for enhanced sealing performance and operational reliability

• Rigid, reinforced ramps capable of accommodating a wide range of heavy vehicles and axle configurations

• Smooth, stable, and synchronized lifting operation for safe handling of high-capacity loads

Hydraulic Pipeline Works (Included)

• MS SH 40 seamless hydraulic pipe – 1½”

• High-pressure hydraulic fittings rated at 3000 PSI

• Grease-coated protective tape for underground pipeline corrosion protection

• Complete hydraulic pipeline installation from two hydraulic receiver tanks to two jack cylinders

Installation & Commissioning – Terms and Conditions

• Installation and commissioning shall be carried out exclusively by MECTRON-authorized technical personnel

• All civil works, including pit construction, foundations, grouting, and finishing, shall be provided by the customer as per approved drawings and technical requirements

• All electrical works, compressed air supply, and utilities shall be arranged by the customer

• Any government approvals, permits, or statutory clearances, if required, shall be obtained by the customer prior to installation

• Installation and after-sales service support are restricted to the UAE only

• Delays due to incomplete civil or electrical readiness will not be the responsibility of the supplier
